EAN:73-30130-01424-4
The Kvaser Leaf v3 is a simple, cost-effective way to connect a computer to a CAN bus network, enabling both monitoring and transmission of CAN and CAN FD data. Featuring a USB 2.0 interface and 9-pin D-SUB connector, it combines a compact, ergonomic design with the durability needed for everyday use – making it ideal even for tight installation spaces.
The Leaf v3 supports up to 20,000 messages per second, each stamped with 50-microsecond precision. It requires no external power supply and includes galvanic isolation as a standard feature.
Tech Specs
| Specification | Details |
|---|---|
| Bit Rate (kbps) | 20 – 1000 kbps |
| Height | 17 mm |
| Length | 165 mm |
| Weight | 110 g |
| Messages Per Second (Receive) | 20,000 mps |
| Messages Per Second (Send) | 20,000 mps |
| Connectors | DSUB 9 |
| Interfaces | USB |
| CAN FD Bitrate | Up to 8 Mbit/s |
| Timestamp Resolution | 50 µs |
| Error Counters Reading | No |
| Error Frame Generation | No |
| Galvanic Isolation | Yes |
| Silent Mode | Yes |
| Regulatory Compliance | CE, FCC |
| Operating System | Windows 10 (32 & 64-bit), Windows 11 (64-bit), Linux |
| Temperature Range | -20 °C to 70 °C |
| t script | No |
| Categories | Interfaces, Hardware, CAN |
| Channels | 1 |
Price: Rs. 26500
Contact us: info@autotechdrive.com
